location：Home>Products>Sensors>Other Sensor>Tipping Bucket Rain Gauge Rainfall Sensor for Weather Station Agriculture
Tipping Bucket Rain Gauge Rainfall Sensor for Weather Station Agriculture
Model：YL1
Brand：fengtu
Tipping bucket rain gauge/Rainfall sensor.The three-dimensional streamlined design is adopted to make the tipping bucket turn water more smoothly, and it has the functions of self-cleaning dust and easy cleaning. Pulse to 485 signal output, can directly read the rainfall, no need for secondary calculation, simple and convenient.
Get a Free Quote- Product details
- Related products
- Related articles
Tipping bucket rain gauge/Rainfall sensor.The three-dimensional streamlined design is adopted to make the tipping bucket turn water more smoothly, and it has the functions of self-cleaning dust and easy cleaning. Pulse to 485 signal output, can directly read the rainfall, no need for secondary calculation, simple and convenient.
1.Technical indicators of Tipping Bucket Rain Gauge Rainfall Sensor for Weather Station Agriculture
1. Power supply: DC12V
2. Power consumption: 0.02W
3. Working environment: 0~50℃
4. Communication interface: RS485
5. Working current: 2mA DC12V
6. Minimum data interval: 0.5S
二、Tipping Bucket Rain Gauge Rainfall Sensor for Weather Station Agriculture参数
| Rain gauge barrel diameter | Φ200mm |
| Operating temperature | 0～50℃ |
| Working humidity | <95%(no condensation) |
| error | ≤±2% |
| resolution | 0.2mm |
| Rain intensity range | 0mm～4mm/min, the maximum rain intensity allowed is 8mm/min |
| Heavy rain intensity range | 0～10mm/min, the maximum rain intensity allowed is 15mm/min |
| output method | Modbus485 |
3. Tipping Bucket Rain Gauge Rainfall Sensor for Weather Station Agriculture Product Dimensions
