Advantages of Pulse Radar Level Meter

Pulse radar level meter integrated design, no movable parts, no mechanical wear and tear, long life. Electromagnetic waves radiated during the measurement process can be propagated in a vacuum without transmission medium, which is characterized by the fact that it is not affected by factors such as atmosphere, vapour and volatile mist in the tank, and can be applied to the measurement of the level of volatile media such as crude benzene. It can be applied to almost all kinds of liquid level measurement. Electromagnetic wave reflected to the surface of the liquid level, the signal will be attenuated, the attenuation is too small, will make the radar level meter can not measure large enough electromagnetic wave signal. Conductive media have a good reflection of electromagnetic waves, for radar level meter, even if the micro-conductive material can reflect enough electromagnetic waves. Dielectric constant of 1.5 or more non-conductive media (air dielectric constant of 1.0) can also ensure that the reflected wave is sufficient, the higher the dielectric constant of the reflected signal is stronger. In practice, almost any medium can reflect sufficiently. Measurement is non-contact and independent of the density, concentration and other physical properties of the liquid in the tank. Wide measuring range, * wide measuring range can reach 0 ~ 35m, can measure high temperature and high pressure liquid level. The antenna and other key components are made of high-quality materials, with strong corrosion resistance, and can adapt to the highly corrosive environment. After measuring the actual liquid level, the software can automatically recognize the false echo from the liquid level to the antenna and eliminate the above fluctuation interference. Parameter setting is simple, can be set through the level meter simple operation key, but also through the HART protocol hand manipulator remote or directly with the level meter communication terminal connection, very convenient.
