water level sensors for water tanks

1.Product principle of water level sensors for water tanks

water level sensors for water tanks Water level sensors for water tanks Water level sensors for water tanks, containers and reservoirs.The radar level antenna emits narrow microwave pulses, which are transmitted downward through the antenna. After the microwave contacts the surface of the measured medium, it is reflected back and is received again by the antenna system. The signal is transmitted to the electronic circuit part and automatically converted into a level signal (because the microwave propagates extremely fast, the electromagnetic wave reaches the target and is reflected back to the receiver. The time taken is almost instantaneous).

2. Technical parameters of water level sensors for water tanks

Application: temperature-resistant, pressure-resistant, slightly corrosive liquids

Measuring range: 30 meters

Process connection: thread, flange

Medium temperature: -40～250℃

Process pressure: -0.1～4.0MPa

Accuracy: ±3mm

Protection level: IP67

Frequency range: 26GHz

Explosion-proof level: ExiaⅡC T6 Ga/Exd ia IIC T6 Gb

Signal output: 4...20mA/HART (two wires/four wires) RS485/Mod bus

3. Product features of water level sensors for water tanks

The antenna is small in size and easy to install; the non-contact radar has no wear and pollution.

Almost unaffected by corrosion and foam; almost unaffected by water vapor, temperature and pressure changes in the atmosphere.

Serious dust environment has little impact on the work of high-frequency level meters.

The shorter wavelength results in better reflection from tilted solid surfaces.

The beam angle is small and the energy is concentrated, which enhances the echo capability and helps avoid interference.

The measurement blind area is smaller, and good results can be achieved for small tank measurements.

High signal-to-noise ratio for better performance even under fluctuating conditions.

High frequency, it is the best choice for measuring solids and low dielectric constant media.
