Recommended instrumentation for hydrological stations

Hydrological station, is an important part of the water measurement and reporting. It plays an irreplaceable role in hydrological forecasting, and it provides the basis for policy formulation. It can both timely and accurate reflection of river water level changes, but also for the analysis of hydrological forecasting to provide basic information. With the needs of national economy and social development, a certain number of hydrological stations have been commonly established in water conservancy departments at all levels, and their management and maintenance.

Recommend a hydrological station instrumentation equipment, its model FT-SW4, can real-time monitoring of hydrological flow, flow rate, water level, rainfall and other data, and has automatic alarm function. It uses radar sensor, small size, light weight, low power consumption, simple and convenient operation, and can be operated continuously. Moreover, it uses solar power supply, which is convenient for field use.

Windway Technology is the manufacturer of the water level station instruments and equipment, we are a professional enterprise engaged in the production and sales of monitoring equipment and instruments, the company was established in 2017, the main products are: hydrological station instruments, portable flow velocity meter, water quality analyzer, various weather stations, etc.. The company to "integrity-based, quality first" business philosophy and the majority of new and old customers sincere cooperation! Welcome friends from all walks of life to consult and discuss business. Our products are widely used in water conservancy projects, urban water supply, urban drainage and sewage treatment.

Through years of continuous research and development and improvement, has now formed a set of scientific research, design, development, manufacturing, sales and service as one of the comprehensive high-tech enterprises, quality of survival, quality of survival, continuous innovation, and continuous improvement of self!

Technical parameters.

Water level measurement

Distance range: 0.4-40m

Distance measuring accuracy: ±1cm

Distance measurement resolution: 1mm

Interval time: 1-5000min

Flow velocity measurement

Range of distance measurement: 0.15~15m/s

Speed measurement accuracy: ±2%

Velocity resolution: 0.01m/s

Flow rate measurement

Flow rate = average flow velocity x cross-flow section area x correction factor

The average flow velocity is collected by the flow meter, and after the model calculation to obtain the fluid surface velocity

Overflow cross-sectional area is calculated from the water level measured by the water level meter and cross-sectional information

Rainfall monitoring

Measuring range: rain intensity 0~4mm/min

Measurement accuracy: ±0.2mm

Resolution: 0.2mm

Rain bearing caliber: φ200mm
