Underwater life detector

1、Underwater life detector Applications:

Underwater life detector is suitable for various complex aquatic environments and, when combined with flying lifeboats and unmanned vessels, improves the efficiency and safety of water rescue operations.

1.Pipe cleaning machines

2.Pipe inspection cameras and pipe tools

3.Underground pipelines, air conditioning ducts, oil and gas pipelines

4.Rescue work in confined spaces

5.Underground exploration

6.Underwater riverbed research

7.Downhole television

2、Underwater life detector Technical Specifications

1.Camera and Cable:

Sensor: 1/3 CMOS

Resolution: AHD

Camera Diameter: 23MM self-balancing 512HZ camera / 32MM self-balancing 512HZ camera / 50MM rotating camera

Maximum Detection Depth/Material: 9MM diameter cable: 50M to 200M (cable length optional)

Camera Light Source: White LED lights

Camera Viewing Angle: 105 degrees

Camera Material: Stainless steel

Lens: Sapphire

Waterproof Rating: Underwater 10 meters

2.Monitor:

Size: 10 inches

Functions: Video recording/Audio recording/Photo taking/Electronic zoom/Battery level display/Electronic meter counter/Keyboard input (supports English)

Camera/Monitoring Image: Color

Monitor Input Voltage: 12V DC

TF Card: Supports up to 128GB TF card, 16GB TF card included as standard

Display Resolution: 1024*600 IPS

Menu Display: Chinese/English/Russian/French/German selectable

Monitor Operation: Buttons

Video Format: AVI

Photo Format: JPG

Operating Temperature: -20-60 degrees Celsius

Storage Temperature: -30-80 degrees Celsius

3.Control Panel Functions:

Power on/off function

LED light five-level adjustment function

Meter/Feet conversion function

Electronic meter counter reset

Rotation control function (function key invalid without rotating camera)

Keyboard input

Video switching function (function key invalid without rotating camera)

Charger: 100VAC-240VAC DC 12.6V 1000MA

Battery: Built-in 4500AH lithium battery

Battery Working Time: Approximately 6-8 hours
